CH7001 – Thermodynamics, Reaction Kinetics & Heat Transfer Problem Set

1.

(a)

Average/mean velocity $v_{avg}=\sqrt{\frac{8RT}{\pi M}}$

T = 25 + 273.15 = 298.15 $M_{He}=4\frac{g}{mol}$ $M_{Hg}=200\frac{g}{mol}$ Not converting to kg as looking at ratios rather than absolute values.

$\frac{\sqrt{\frac{8(8.314)(298.15)}{4\pi }}}{\sqrt{\frac{8(8.314)(298.15)}{200\pi }}}=7$

$ke(He)=\frac{1}{2}(4)(v_{avg}(He){)}^2;ke(Hg)=\frac{1}{2}(4)(v_{avg}(Hg){)}^2$ $\frac{ke(He)}{ke(Hg)}=1$

(b)

T = 20 + 273.15 = 293.15

$v_{rms}=\sqrt{\frac{3RT}{M}}$

$v_{rms}(C{O}_2)=\sqrt{\frac{3R\ast 293.15}{\frac{44.01}{1000}}}=407.6m/s$ $v_{rms}(He)=\sqrt{\frac{3R\ast 293.15}{\frac{4}{1000}}}=1352m/s$

2. $n=2;p=1.25atm;\Delta T=27K;C_p=37.11\frac{J}{K\ast mol}$

At constant pressure heat is the same as change in enthalpy. $C_p=\frac{\Delta H}{\Delta T};\Delta H=1001.97J;q_p=\Delta H=1001.97J$

U = 1006.36J$$ **3.** Mass of benzene: $m_b$ $$ m_b = 0.00075kg*876.6; M_b = 78.11 \frac{g}{mol}$$ $$ n_b = \frac{m_b}{0.001*M_b} = 0.84 moles $$ because the unknown substance is involtaile it does not contribute to the vapor pressure $$ 25 torr = (192 torr)x_b \rightarrow x_b = 0.13 $$ If 0.84 moles is $0.13$ of the total amount of moles there are $6.47$ moles in total. $$20g = 5.63 moles \rightarrow 3.55 \frac{g}{mol}$$ **4.** $$ T = 273.15 + 50 = 323.15K; $$ Assuming that this reaction is taking place at constant pressure so that we can use entropy in the gibbs energy of the reaction. $$ \Delta{S_{net}} = \frac{\Delta{H_{net}}}{T} = \frac{-134.47 + 3(-92.31) + 50.72}{323.15} = -1.12 \frac{kJ}{mol*K}$$ $$ \Delta_r{G} = \Delta{H_{net}} - \Delta{T S_{net}} = -388 \frac{kJ}{mol}$$ $$ \Delta_r{G^0} = -73.66 + 3(-95.30) + 50.72 = -308.84 \frac{kj}{mol}$$ $$ K = exp[\frac{-\Delta_r{G^0}}{0.008314*323.15}] = 8.38\times10^{49}$$ **5.** **a)** If the bomb calorimeter gains 598 Joules of energy for each K increase then it's gained $598*8.1 = 4843.8$ Joules of energy. This is heat lost by the system so $$\Delta U = q_v = -4843J$$ Molecular weight of glucose $$M = 179.4 \frac{g}{mol}$$ $$\Delta{U^0} = \frac{-4843}{\frac{0.3}{179.4}} = 2900.0479 \frac{kJ}{mol}$$ **b)** Because there is no change in volume $$\Delta{H^0_{com}} = -2900\frac{kJ}{mol}$$ **c)** $$ \Delta_f H^0(CO_2) = -393.51 \frac{kJ}{mol}$$ $$ \Delta_f H^0(H_20) = -285.83 \frac{kJ}{mol}$$ $$ \Delta_fH^0 = 6(\Delta_f H^0(CO_2)) + 6(\Delta_f H^0(H_20)) = -4079 \frac{kJ}{mol} $$ Gibbs energy of reaction is gibbs energy of the products minus that of the reactants. $$ 2900.0479 \frac{kJ}{mol} = -4079 - \Delta_fH^0(C_6H_{12}O_6)$$ $$\Delta_fH^0(C_6H_{12}O_6) = -1179 \frac{kJ}{mol}$$ **d)** Unsure as to what quantities to use to analyse combustion in anaerobic glycolysis. **6. a)** { height=50% width=50%} **b)** The temperature when the vapor pressure is 1 atm (0.101 MPa) is approximately 111K. **c)** There's no change in temperature so no change in internal energy. Just the work to change the volume against constant pressure (1atm). $$ \Delta V = 9.05 - 4.1\times10^{-2} = 9.009 \frac{dm^3}{mol}; \Delta{H_{vap}} = (-1.013\times10^5 Pa)(0.09009 \frac{m^3}{mol}) = -9.126 \frac{kJ}{mol}$$ **7. ** $$Q = \frac{[C]^2[D]}{[A][B]^3}$$ After reaction the product D increases by 0.2 moles with A losing that amount along with B. The loss $x = 0.2$. $$\frac{0.2^3}{(4-0.2)(2-0.2)^3} = 3.6\times10^{-4}$$ **8.** **a)** For each reaction, calculate $\Delta_rG$. The activity of solids are 1. for $H_2O(g) \rightarrow H_2O(s)$ $$\Delta_rG = -23.6 \frac{kJ}{mol} + (0.008314)(190)ln(\frac{1}{0.13\times10^{-6}}) = 0.9 \frac{kJ}{mol}$$ for $H_2O(g) + HNO_3(g) \rightarrow HNO_3 \cdot H_2O(s)$ $$\Delta_rG = -57.2 \frac{kJ}{mol} + (0.008314)(190)ln(\frac{1}{0.13\times10^{-6}*0.41\times10^{-9}}) = 0.7 \frac{kJ}{mol}$$ for $2H_2O(g) + HNO_3(g) \rightarrow HNO_3 \cdot 2H_2O(s)$ $$\Delta_rG = -85.6 \frac{kJ}{mol} + (0.008314)(190)ln(\frac{1}{(0.13\times10^{-6})^2*0.41\times10^{-9}}) = -3.2 \frac{kJ}{mol}$$ for $3H_2O(g) + HNO_3(g) \rightarrow HNO_3 \cdot 3H_2O(s)$ $$\Delta_rG = -85.6 \frac{kJ}{mol} + (0.008314)(190)ln(\frac{1}{(0.13\times10^{-6})^3*0.41\times10^{-9}}) = -5.8 \frac{kJ}{mol}$$ The last two reactions seem spontaneous, the deepest gibbs energy well being the final reaction $3H_2O(g) + HNO_3(g) \rightarrow HNO_3 \cdot 3H_2O(s)$ the most thermodynamically stable. **b)** If enthalpy of formation is considered $\Delta_rG$ for each solid, from part a. for $HNO_3 \cdot 2H_2O(s) \rightarrow HNO_3 \cdot 3H_2O(s)$ $$\Delta_rG = -5.8 - (-3.2) = -2.6\frac{kJ}{mol}$$ for $HNO_3 \cdot 3H_2O(s) \rightarrow HNO_3 \cdot 2H_2O(s)$ $$\Delta_rG = -3.2 - (-5.8) = 2.6\frac{kJ}{mol}$$ Going from $HNO_3 \cdot 2H_2O(s) \rightarrow HNO_3 \cdot 3H_2O(s)$ is more spontaneous, meaning $HNO_3 \cdot 3H_2O(s)$ is more thermodynamically stable. **9.** **a)** From experiment 3 to 2, $[Cl_2]$ is kept constant and [NO] is doubled. This results in the reaction rate increasing by a factor of 8 $\frac{2.2\times10^{-3}}{2.7\times10^{-4}} = 8.1$, this would put a relationship of $r = k[NO]^3$ on the concentration of [NO]. From experiment 1 to 3, $[NO]$ is kept constant and $[Cl_2]$ is doubled. This results in the reaction rate increasing by a factor of 8 $\frac{2.7\times10^{-4}}{6.7\times10^{-5}} = 4$, this would put a relationship of $r = k[Cl_2]^2$ on the concentration of $[Cl_2]$. the reaction rate law would then be $r = [Cl_2]^3[NO]^2$ an order of 5. **b)** The rate constant $k$ doesn't change for concentrations. From experiment $$k = \frac{6.7\times10^{-5}}{0.015^3*0.050^2} = 7940.7 \frac{1}{M^4s}$$ for experiment 4 then $$r = k[NO]^3[Cl_2]^2 = 2.4\times10^{-3}$$ **10.** **a)** ![Plot of ln[A] against time](img/orderofreactionassignmentgraph.png){ height=50% width=50%} The rate constant is the slope of the above graph. $$ln[A] = ln[A]_0 - k_{obs}t$$ $$ln[A]_0 = 2.314 \text{ from the graph}$$ $$k = -0.0486 \text{ picking two points from the graph}$$ **b)** $$y = 2.314 - 0.0486t \rightarrow y(t=43.8) = 0.185$$ $$e^{0.0185} = 1.2\frac{\times10^{-2}mol}{dm^3}$$ Taking the mass of $(CH_3)_3CBr = 137 \frac{g}{mol}$ after 43.8 hours we have $137*1.2\times10^{-2} = 1.6 \frac{grams}{dm^3}$.
